The RAM X-Grip is the perfect holder for virtually any phone or tablet with or without a case.

The RAM X-Grip Large Phone Mount with RAM Vibe-Safe & U-Bolt Base – Short (RAM-B-149Z-A-UN10-462) is a combination of the RAM X-Grip Phone Mount with Handlebar U-Bolt Base and the RAM Vibe-Safe. Our vibration-damping accessory is designed to protect electronic devices from a wide range of vibration frequencies.

This product comes pre-assembled with the device tether that is recommended for outdoor applications. The RAM X-Grip can rotate between portrait and landscape by loosening the center screw. This product comes with one (1) short B size arm and one (1) RAM U-Bolt Base that accommodates rails from 0.5″ – 1.25″ in diameter and an optional device tether that is recommended for outdoor applications.

Features:

• RAM Vibe-Safe dampens a wide range of vibration frequencies
• Made of high-strength composite and stainless steel hardware for durability and reliability in the most demanding environments
• Unique structure and thoughtfully designed with all industries in mind
• Backed by a lifetime warranty

Hardware Included:

• (1) Optional Tether
• (1) Glue Tube for Rubber Caps
• (1) 1/4″-20 U-Bolt for 0.5″ – 1″ Rails
• (1) 1/4″-20 U-Bolt for 1″ – 1.25″ Rails
• (2) 1/4″-20 Nylock Nuts
• (2) Rubber Caps
• (1) U-Bolt Spacer

Holder Dimensions:

• Width Range: 1.75″ – 4.5″
• Depth Range: 0.875″ max

Clamp Range:

• 0.5″ – 1.25″ diameter

Socket-to-Socket Length:

• 1.75″

Ball Size:

• B Size (1″)

Weight Capacity:

• Standard Use: 2 lbs
• Heavy-Duty Use: 1 lb

Materials:

• Marine-grade aluminium
• High strength composite
• Stainless steel

Packaging Type:

• Retail Bag

Additional Information:

• A reduction in vibration does not guarantee full protection of the device. External immeasurable factors may cause damage to phones, cameras, and other devices while mounted in the RAM Vibe-Safe. National Products, Inc does not assume responsibility or liability for any such personal injury, death, or property damage. RAM mounts lifetime warranty is limited to RAM mounts and components. The warranty does not include any device mounted or attached to a RAM mount, such as a phone, GPS, camera, computer, or other device.
